Bobbins and Spools
There are 50 results
| Title | Equipment | Flange Dia. | Traverse | Barrel Dia. | Bore Size | Drive Type | |
|---|---|---|---|---|---|---|---|
| #4 Braider | N E Butt/Wardwell | 4.00" 101.60mm |
6.0" to 7.0" in .5" increments 152.40mm to 177.80mm in 12.7mm increments |
|
.406", .441", .506" 10.31mm, 11.20mm, 12.85mm |
10 tooth ratchet |
|
| #4-EL | N E Butt/Wardwell | 4.00" 101.60mm |
9.0" to 16.0" in .5" increments 228.60mm to 406.40mm in 12.7mm increments |
|
.385" or .510" 9.78mm or 12.95mm |
10 tooth ratchet |
|
| #4-SDF | N E Butt/Wardwell | 3.375" 84.73mm |
6.0" to 8.0" in .5" increments 152.40mm to 203.20mm in 12.7mm increments |
|
.406", .441", .506" 10.31mm, 11.20mm, 12.85mm |
10 tooth ratchet |
|
| 10" Steeger | Steeger | 2.75" 69.85mm |
9.560" 242.88mm |
|
.688mm 17.48mm |
Drive Slot |
|
| 13" Steeger | Steeger | 3.72" 94.49mm |
11.50" 292.10mm |
|
.89" 22.61mm |
Drive Slot |
|
| 16CBB | 2.59" 65.79mm |
2.72" 65.09mm |
|
.65" 16.51mm |
|
|
|
| 2 BDX | N E Butt/Wardwell | 2.75" 190.50mm |
6.0" to 8.0" in .5" increments 152.40mm to 203.20mm in 12.7mm increments |
|
.406", .441", .506" 10.31mm, 11.20mm, 12.85mm |
8 tooth ratchet |
|
| 2 BDX-EL | N E Butt/Wardwell | 2.75" 69.85mm |
7.5" to 13" in .5" increments 190.50mm to 330.20mm in 12.7mm increments |
|
.385" or .510" 9.78mm or 12.95mm |
8 tooth ratchet |
|
| 2 BDX-HC | N E Butt/Wardwell | 2.625" 66.68mm |
6" to 8" in .5" increments 152.40mm to 203.20mm in 12.7mm increments |
|
.406", .441", & .505" 10.31mm, 11.20mm, 12.85mm |
8 tooth ratchet |
|
| 2.2 Bobbins | Hacoba | .980" 24.90mm |
2.210" 56.13mm |
|
.334" 8.48mm |
Right & Left Drives |
|
| 24CBB | 2.59" 65.79mm |
4.08" 103.63mm |
|
.65" 16.51mm |
|
|
|
| 3-EL | N E Butt/Wardwell | 3.50" 88.90mm |
7.5" to 13" in .5" increments 190.50mm to 330.20mm in 12.7mm increments |
|
.385" or .510" 9.78mm or 12.95mm |
10 tooth ratchet |
|
| 38mm | Steeger | 1.50" 38.10mm |
4.33" 109.98mm |
|
.440" 11.18mm |
Drive Slots |
|
| 4 x 4 | Spirka | 3.812" 96.82mm |
3.125" 79.38mm |
|
.390" or .625" 9.91mm or 15.88mm |
Drive Slot |
|
| 42mm | Steeger | 1.65" 42mm |
4.33" 109.98mm |
|
.440" 16.38mm |
Drive Slots |
|
| 63 x 170 | Ratera, Herzog | 2.50" 63.50mm |
6.69" 170.00mm |
|
.55" 13.97mm |
7 pin slots |
|
| 63 x 200 | Ratera, Herzog | 2.50" 63.50mm |
7.87" 200.00mm |
|
.55" 13.97mm |
7 pin slot |
|
| A Spool (1oz.) | Thread | 1.687" 42.85mm |
2.00" see notes 50.80mm |
|
.310" 7.87mm |
|
|
| B Spool (2 oz.) | Thread | 2.125" 53.98mm |
2.00" see notes 50.50mm |
|
.312" 7.92mm |
|
|
| C S Rug Braider | N E Butt/Wardwell | 4.60" 116.84mm |
7.00" 177.80mm |
|
.500" 12.70mm |
12 ratchet teeth |
|
| Cop Holder #2BDX | N E Butt/Wardwell | no top flange no top flange |
smooth with ribs smooth with ribs |
|
|
8 tooth ratchet |
|
| Cop Holder 6 RATT | N E Butt/Wardwell | no top flange no top flange |
smooth with ribs smooth with ribs |
|
.325" 8.26mm |
6 tooth ratchet |
|
| Cop Holder 8 RATT | N E Butt/Wardwell | no top flange no top flange |
smooth with ribs smooth with ribs |
|
.325" 8.26mm |
8 tooth ratchet |
|
| Cop Holder 8 TABT | N E Butt/Wardwell | no top flange no top flange |
smooth with ribs smooth with ribs |
|
.325" 8.26mm |
8 tooth tabs |
|
| Cop Holder D118R | N E Butt/Wardwell | |
|
|
.33" 8.38mm |
8 tooth ratchet |
|
| CP S 3x3 ST | Spirka | 3.15" 80mm |
3.16" 80.26mm |
|
.395" 10.03mm |
Drive Slot |
|
| CP-1212-100 | Herzog | 2.84" 72mm |
11.25" 285 mm |
|
.50" 12.7 mm |
Slot |
|
| CP-1212-75 | Herzog | 2.875" 73 mm |
11.250" 285 mm |
|
.5" 12.7 mm |
Slot |
|
| CP-140 | Ratera, Herzog | 3.08" 78.23mm |
11.05" 280.67mm |
|
.590" 14.99mm |
pins & slots |
|
| CP-16 | Wardwell | 2.60" 66.04mm |
2.875" +/- .010 73.03 mm |
|
.660" 16.76mm |
|
|
| CP-180 | Herzog | 3.54" 89.92mm |
11.89" 302mm |
|
.59" 15mm |
|
|
| CP-1X1 | Thread | 1.693" 43mm |
1.013" 25.7mm |
|
.417" 10.6mm |
|
|
| CP-224L | Herzog | 4.70" 119.40mm |
13.75" 349.30mm |
|
.610" 15.50mm |
Bore or Slot |
|
| CP-224S | Herzog | 4.70" 119.40mm |
11.30" 287.00mm |
|
.610" 15.50mm |
Bore or Slot |
|
| CP-24 | Wardwell | 2.59" 65.79mm |
4.20" 106.68mm |
|
.660" 16.76mm |
|
|
| CP-338 | 3.38" 85.7mm |
3.00" 76.2mm |
|
1.65" 41.3mm |
|
|
|
| CP-3x3 | Spirka | 3.14" 78.49mm |
3.15" 80.00mm |
|
.400" 10.16mm |
Drive Slot |
|
| CP-40 x 16 | Steeger | 1.565" 39.75mm |
1.025" 26.04mm |
|
.410" 10.41mm |
8 Tooth Ratchet |
|
| CP-40 x 26 | Steeger | 1.565" 39.75mm |
1.025" 26.04mm |
|
.410" 10.41mm |
8 Tooth Ratchet |
|
| CP-40 x 30 | Steeger | 1.565" 39.75mm |
1.025" 26.04mm |
|
.410" 10.41mm |
8 Tooth Ratchet |
|
| CP-7.5 | Ratera 154 | 2.58" 65.53mm |
6.67" 169.42mm |
|
.64" 16.51mm |
Slot - bottom flange |
|
| CRB-01 | Hacoba | 2.59" 65.78mm |
2.72" 69.09mm |
|
.65" 16.51mm |
|
|
| CRB-2 | Hacoba | 2.59" 65.78mm |
4.07" 103.38mm |
|
.65" 16.51mm |
|
|
| Jette Spool | Herzog | 4.00" 101.60mm |
7.062" 179.38mm |
|
.531" 26.97mm typical, smooth |
Drive Slots |
|
| Kokobun | Kokobun | 5.22" 132.59mm |
7.12" 180.85mm |
|
.620" 15.75mm |
10 tooth ratchet |
|
| No 27 spool | 3.5" 89.9mm |
2.18" 35.37mm |
|
2.14" 54.36mm |
1/4" 6.35mm slots |
|
|
| No. 1 Bobbin | N E Butt/Wardwell | 1.32" & 1.46" 33.53mm & 37.08mm |
Smooth 3" to 6"; Textured. 3.3" Smooth 76.20mm to 154.40mm; Textured, 83.82mm |
|
.325" 8.26mm |
6 Tooth Ratchet |
|
| No. 2 Bobbin | N E Butt/Wardwell | 1.81" Button or Flat Head, 1.83" Double Head 45.97mm Button or Flat Head, 46.84mm Double Head |
4" to 6" 101.60mm to 152.40mm |
|
.330" & .450" 8.38mm & 11.43mm |
6 & 8 tooth ratchet, 8 tab tooth |
|
| No. 2 Fine Wire | N E Butt/Wardwell | 1.82" Wide Button Head 46.23mm Wide Button Head |
Smooth 2.5" & 2.75" Smooth 63.50mm & 69.85mm |
|
.325" 8.26mm |
6 & 8 tooth ratchet, 8 tab tooth |
|
| Sashcord Bobbin | N E Butt/Wardwell | 4.00" 101.60mm |
6.0" to 7.0" in .5" increments 152.40mm to 177.80mm in 12.7mm increments |
|
.406", .441", .506" 10.31mm, 11.20mm, 12.85mm |
2 Hole Pin Drive |
|
